Technical Data Overview

Input Data

• AC Operation:
  • Nominal Voltage: 100–240 V AC
  • Voltage Range: 85–264 V AC; DC: 120–375 V DC
  • Frequency: 47–63 Hz
  • Inrush Current: 20 A (115 V AC), 40 A (230 V AC)
  • Mains Buffering: 10 ms (115 V AC), 20 ms (230 V AC)
  • Current Consumption: 2.8 A (115 V AC), 1.4 A (230 V AC)
  • Power Consumption: 273.22 VA
  • Protective Circuit: Surge protection, Varistor
  • Response Time: 1000 ms
  • Input Fuse: 6.3 A (slow-blow, internal)
  • Discharge Current to PE: < 1 mA (at 264 V AC)

Output Data

• Efficiency:
  • 88% (115 V AC)
  • 90% (230 V AC)
• Output Voltage: 24 V DC ±2% (adjustable: 22–28 V DC, max. 240 W)
• Output Current: 10 A nominal
• Power:
  • Nominal Output: 240 W
  • No-Load Dissipation: 4.62 W (115 V AC), 2.14 W (230 V AC)
  • Max. Power Loss: 31.53 W (115 V AC)
• Load and Ripple:
  • Max. Capacitive Load: 8000 μF
  • Residual Ripple: < 120 mVPP (-10°C to +70°C); < 240 mVPP (-20°C to -10°C)
  • Static Regulation: ≤ 1% (10–90% load)
  • Dynamic Regulation: ±2% (10–90% load)
• Derating:

  • 40°C: 1.67%/°C (115 V AC)

  • 50°C: 2.5%/°C (230 V AC)

• Current Limitation: 105–150% of max. output power during short circuit.
